Summary

Stauff RL-130-B-25-B Replaces the Stauff RL130B25B

Stauff RL130B25B
Representative product image Product image feedback

Stauff RL-130-B-25-B Replaces the Stauff RL130B25B

RL-130-B-25-B
Stauff
Stauff RL130B25B
Description

Replacement Filter Element for Return-Line Filters Micron Rating: 25 µm Material: Stainless Mesh Outer Diameter (mm): 129,5 Inner Diameter (mm): 73,3 Length (mm): 483,5 Sealing: NBR, β ratio >2

Brand: Stauff
Price Matched
$1,050.00
2.56 kg
8421.99.90
Germany
3.14 kg
8421.99.90
Italy
8421.99.90
France
Shipping Terms

Description

Replacement Filter Element for Return-Line Filters Micron Rating: 25 µm Material: Stainless Mesh Outer Diameter (mm): 129,5 Inner Diameter (mm): 73,3 Length (mm): 483,5 Sealing: NBR, β ratio >2

Specification

StyleReturn Filter
Efficiency 125µ
Outer Diameter 130 mm
Inner Diameter 73.3 mm
Length 480 mm
MediaWire Mesh
Flow DirectionOUT-IN
Δ Collapse Pressure 16 BAR
Seal MaterialNitrile
Temperature Range -30 - +100°C

Genuine Product

Find out more
Stauff Brand Logo

Stauff Product

Genuine Stauff RL-130-B-25-B

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
25µ
Efficiency 2
Style Return Filter
Outer Diameter 130 mm
Inner Diameter 73.3 mm
Length 480 mm
Media Type Wire Mesh
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 16 BAR
Seal Nitrile
Temperature Range -30 - +100°C
