MICROFIT MFHC60193 Replaces the MP Filtri MP67641

MICROFIT MFHC60193
Representative product image Product image feedback

MICROFIT® UltraGen III MFHC60193 Replaces the MP Filtri MP67641

MFHC60193
MICROFIT
MP Filtri MP67641
Description

The MICROFIT® UltraGen III MFHC60193 is the MICROFIT® approved replacement to the MP Filtri MP67641. Engineered and manufactured in Great Britain the MFHC60193

Brand: MICROFIT
Price Matched
$329.00
3.2 kg
8421.99.90
United Kingdom
1.92 kg
8421.99.90
France
1.45 kg
8421.99.90
Italy
Shipping Terms

Description

The MICROFIT® UltraGen III MFHC60193 is the MICROFIT® approved replacement to the MP Filtri MP67641. Engineered and manufactured in Great Britain the MFHC60193

Specification

StyleCoreless Filter
Efficiency 15µ @ β200
Efficiency 27µ @ β1000
Outer Diameter 137.0 mm
Inner Diameter 99.5 mm
Length 515.0 mm
MediaGlass Fiber
Flow DirectionOUT-IN
Δ Collapse Pressure 10 BAR
Seal MaterialNitrile
Temperature Range -30 - +100°C

Approved Product

Find out more
MP Filtri Brand Logo

Same Fit-Form & Function

As the Genuine MP Filtri MP67641

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
5µ @ β200
Efficiency 2 7µ @ β1000
Style Coreless Filter
Outer Diameter 137.0 mm
Inner Diameter 99.5 mm
Length 515.0 mm
Media Type Glass Fiber
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 10 BAR
Seal Nitrile
Temperature Range -30 - +100°C
