Summary

Fleetguard HF6778 Replacement Spin-On Filter

Fleetguard HF6778
Fleetguard HF6778
Representative product image Product image feedback

Fleetguard HF6778 Spin-On Filter

Brand: Fleetguard
Description

Fleetguard® HF6778 hydraulic spin-on filter with synthetic media is designed to help keep your precision hydraulic systems running as intended, providing a solution for various applications. This filter meets or exceeds the equipment OEM quality and performance and is the first aftermarket replacement available on the market today, bringing your operation top-quality performance and an overall unbeatable total cost of ownership.

Price Match
Rs. 9,900.00
1.6 kg
0.0065 m³
147 pcs
United States
8421.99.90
1.6 kg
0.0055 m³
147 pcs
United States
8421.29.80.90
1.72 kg
0.0061 m³
147 pcs
France
8421.99.90
147 pcs
United States
8421.23.00
1.54 kg
0.0044 m³
147 pcs
Italy
8421.99.90
Shipping Terms

Description

Fleetguard® HF6778 hydraulic spin-on filter with synthetic media is designed to help keep your precision hydraulic systems running as intended, providing a solution for various applications. This filter meets or exceeds the equipment OEM quality and performance and is the first aftermarket replacement available on the market today, bringing your operation top-quality performance and an overall unbeatable total cost of ownership.

Specification

StyleSpin-On Filter
MediaGlass Fiber
Efficiency 15µ @ β200
Efficiency 27µ @ β1000
Outer Diameter 128.0 mm
Length 266.0 mm
Thread1 1/2"-16 UN
Δ Collapse Pressure 14 bar
Seal MaterialNitrile
Temperature Range -30 - +100°C
Fleetguard Brand Logo

Fleetguard Product

Genuine Fleetguard HF6778

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Fleetguard Warranty

Fleetguard Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
5µ @ β200
Efficiency 2 7µ @ β1000
Style Spin-On Filter
Outer Diameter 128.0 mm
Inner Diameter
Length 266.0 mm
Media Type Glass Fiber
Flow Direction
Thread 1 1/2"-16 UN
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 14 BAR
Seal Nitrile
Temperature Range -30 - +100°C
